The Tesla diode Ring resonator is able to receive and amplify its own vibrations at the expense of spurious frequencies so much that, when powered by just one wire from the antenna, it lights a cheap Chinese light bulb, though not brightly. The design is not complicated and incomprehensible - the inductor consisting of 1150 turns is closed to a high-voltage diode KC106 assembled from several silicon diodes. According to the scheme, it is easy to guess that this is nothing more than an Inductively controlled Varicap that can simultaneously resonate with an Inductive coil at high frequencies as a low-capacity capacitor and rectify high-frequency currents that occur in the Resonant circuit. This design is patented in many countries of the world under different numbers and surnames. The simple principle underlying it has led to the fact that in many developed countries, engineers have come up with how to use the properties of a Diode Ring Resonator in radio communications and in experiments on the transmission of electrical energy over a distance by means of high-frequency waves and Resonators. #TeslaDiodeRingResonator
