– Legal Eagle Part 103 Legal Ultralight Aircraft by Leonard Milholland - produced in kit form by J&N Bolding Enterprises of Baytown, Texas and intended for amateur construction. The Legal Eagle is so named because it is capable of being built in legal compliance with the United States FAR 103 Ultralight Vehicles regulations, even when equipped with a four stroke engine. The Legal Eagle features an open cockpit and is powered by a 30 hp (22 kW) Half VW engine. The design features a fuselage of welded 4130 steel tubing, mated to an all-wood wing made from spruce. The struts and tail surfaces are made from 6061 T6 aluminium tubing. The flying surfaces are covered with doped aircraft fabric. The rear fuselage is normally left as an open truss structure to save weight and to ensure that the aircraft does not exceed the FAR 103 maximum speed of 55 knots (102 km/h; 63 mph). Like the fuselage, the taildragger landing gear is sprung steel. The aircraft has been developed into several variants of the basic design including the XL version for larger pilots and a two-seat ultralight trainer and Light-sport aircraft.[6][7][8] Legal Eagle Basic model with a 244 lb (111 kg) empty weight, powered by a 30 hp (22 kW) Half VW engine Legal Eagle XL Model for larger pilots with a wider and taller seat, greater wing area and longer tail. 246 lb (112 kg) empty weight Double Eagle Model with two seats in side-by-side configuration with a 385 lb (175 kg) empty weight and a 900 lb (408 kg) gross weight. Designed as an ultralight trainer and Light Sport Aircraft. Powered by a 60 hp (45 kW) Volkswagen air-cooled engine giving a 70 mph (113 km/h) cruise speed. General characteristics Crew: one Length: 13 ft 0 in ( m) Wingspan: 23 ft 6 in ( m) Height: 5 ft 6 in ( m) Wing area: 107 sq ft (9.9 m2) Empty weight: 244 lb (111 kg) Gross weight: 500 lb (227 kg) Fuel capacity: 5 US gallons (38 litres) Powerplant: 1 × Half VW horizontally opposed twin-cylinder, four-stroke, single ignition aircraft engine, 30 hp (22 kW) Propellers: 2-bladed Culver wooden Performance Maximum speed: 60 mph (97 km/h; 52 kn) Cruise speed: 50 mph (80 km/h; 43 kn) Stall speed: 25 mph (40 km/h; 22 kn) Never exceed speed: 80 mph (129 km/h; 70 kn) Range: 100 mi (87 nmi; 161 km) Rate of climb: 300 ft/min (1.5 m/s) Wing loading: 4.7 lb/sq ft (23 kg/m2) Video and Audio content is Copyright © Sport Aviation Magazine. This video and audio material may not be reproduced in any form without written permission. Help support The Light Sport & Ultralight Flyer by subscribing to The Ultralight Flyer Web Video Magazine at: RELATED SEARCH TERMS: experimental aircraft, experimental amateurbuilt aircraft video, homebuilt aircraft, homebuilt aircraft kits, home built aircraft, homebuilt aircraft plans, sport aircraft, light sport aircraft, light sport aircraft kits, light sport aircraft for sale, light sport aircraft manufacturers, sport planes,sport aircraft, light sport planes, Light-sport Aircraft (Aircraft Type), Flying (Magazine), TAGS: legal eagle ultralight, legal eagle xl, legal eagle ultralight for sale, legal eagle ultralight kits, milholland legal eagle, legal eagle ultralight cost, legal eagle ultralight plans free, legal eagle ultralight reviews, legal eagle ultralight airplane, legal eagle, legal eagle video, milholland, legal eagle ultralight plans pdf, legal eagle ultralight build, legal eagle ultralight plans, legal eagle ultralight aircraft, legal eagle ultralight flying, - Legal Eagle Part 103 Legal Ultralight Aircraft by Leonard Milholland
