This is a LIDL chuck glider conversion into a twin motor RC plane. I call it the “TWIN TURBO LIDL“. The time lapse build video will show you the complete build of a 7,99 EUR kids toy into a fast and highly maneuverable RC plane. With the video and my information below (parts list, plan, STL files) you can also build your own one. If you haven't got a LIDL glider just wait until around May/June where LIDL will have them on sale in the store and in their online shops ... every year! Links to my other LIDL glider conversion videos: LIDL A-10: LIDL DEVIL: LIDL Version 1: Specs: Wingspan: 860mm Length: 680mm Wing area: 11.9 dm2 Weight (AUW): 580g (in my configuration) RC functions: elevator, ailerons, motor, differential thrust CG: 60mm from leading edge My configuration: Basic plane: LIDL Playtive Glider (2021 version) Motor: 2x Graupner Ultra 2806 2300kv brushless motor (2206 stator) Prop: 2x HQ 3-blade 5x4,3 Battery: SLS Quantum 1800mAh 3S 30C/60C ESC: 2x Graupner Brushless Control T 18 XT-60 Receiver: Graupner GR-12 HoTT, 6 channel Servos: 3x Emax ES08D II Other parts and material: Carbon fiber tube 5 x 4mm Carbon fiber rod 1 x 3mm Piano wire 1,0mm for control rods BBQ Skewer (bamboo) Y-Cable XT-60 (homemade) Servo extension 300mm Clear packing tape: tesapack Packband “Crystal Clear“ Beech rod diameter 5mm for canopy locking Plywood for canopy locking Canopy Lock (Pichler Extron): PU glue Screws for attaching motors: M3x4mm Stickers: d-c-fix vinyl silver (mat) and white (mat) Painters tape (for making the markings): tesa Perfect Painters tape blue (hot glue doesn't stick to it and doesn't melt it): tesa Malerband für Lacke Link to plan: Link to free STL files for 3D printed parts (control horn, form part under powerpod): Link to powerpod (MT2206_16x19mm_Standard): :1096211/files Note: If you don't have a 3D printer you can easily make these parts from plywood and balsa wood Note: This video is not sponsored. I only recommend the stuff I used and that worked well for me. Tools: Dremel 3000 Dremel Carving Bit (193) Multipurpose Cutting Kit (565) Dremel Multipurpose Carving Bit (561) Cutting machine: BROTHER ScanNCut SDX1000 Camera: Sony HDR-CX730 Microphone: Rode NTUSB
